LIONPASTE Electro-Conductive Paste

What is the electro-conductive paste “LIONPASTE?”

LIONPASTE is a liquefied form of "KETJENBLACK" high-performance, high-quality carbon black. LIONPASTE is used as an electro-conductive material in such fields as paints/inks, batteries, construction materials and EMI devices.

LIONPASTE W series grades and applications

Item	LIONPASTE W-310A	LIONPASTE W-311N	LIONPASTE W-376R	LIONPASTE W-370C
Appearance	Black liquid	Black liquid	Black liquid	Black liquid
Surface resistivity^* *(mho/cm²)	1.0×10⁵ max	1.0×10⁵ max	1.0×10⁵ max	1.0×10⁵ max
Solid content (%)	17.5	16.5	12.5	15.5
pH	11.0	8.5	9.0	9.0
Viscosity(mPa・s)	600	150	250	100
Ionicity	Anionic	Nonionic	Nonionic	Cationic
Application examples	LIONPASTE is added to various types of plastic, rubber, paint, coating agents and adhesives as an electro-conductive agent. Examples include: Packing material: Applied to paper and plastic to prevent static electricity buildup Carpet backing: Provides effective grounding Sealing material against electromagnetic waves: Makes urethane foam electro-conductive, allowing it to absorb electromagnetic wave

*Test conditions: LIONPASTE/Binder (N.V.48.0%)/water=20/20/60, coating amount 23g/m²

LIONPASTE related information

Examples of properties when used as a paper coating

(1) Test method

1.Compounded paste in the following formulation
2. Applied paste to copy paper using a #10 bar coater
3. Measured the surface resistivity of the coated paper

	(1)	(2)	(3)
LIONPASTE	10	20	40
Binder	10	20	40
Water	80	60	20
Total	100	100	100

*Test conditions: LIONPASTE/Binder (N.V.48.0%)/water=20/20/60, coating amount 23g/m²

(2) Results

	Surface resistivity (mho/cm²)
	(1)	(2)	(3)
LIONPASTE W-310A	2.38×10⁴	7.50×10³	2.77×10³
LIONPASTE W-311N	2.83×10⁵	4.08×10⁴	5.60×10³
LIONPASTE W-376R	3.98×10⁴	1.05×10⁴	3.62×10³

*Measured conditions: Temperature: 20C° Humidity: 56%
